| Model | High-End SQ subwoofer |
|---|---|
| Diameter | 25 cm / 10″ |
| Power Handling (RMS) | 500 Watts |
| Impedance | 2x 2 Ohms |
| Efficiency | 87 dB |
| Power recommendation | 300 – 600 Watts |
| Voice coil | 50 mm / 2″ copper |
| Max. Excursion (Xmax) | 40 mm / 1.57″ |
| Mounting depth | 128 mm / 5.04″ |
| Resonance frequency (Fs) | 31 Hz |
| Overall quality (Qts) | 0.53 |
| Equiv. air volume (Vas) | 31.47 L / 1.11 cu.ft. |
